The SLC-457 Electronic Timer is designed for time counting in range from 0 to 100 hours with resolution of 1 min. Actual result is showed on 4-digit display, and the user can change it’s bright in 8 steps range. The device is equipped with 4 buttons for main presets programming. To get high protection level, the keyboard is mounted under transparent waterproof cover. This feature allows to use SLC-457 in hazardous environments.
Features
- timer in tight, wall mounting case, IP 67
- 4 x 57 mm LED display, brightness adjustable in 8 steps
- pulse input START - counting enable
- input RESET - clear counter
- power supply output: 24V DC
- RS-485 / Modbus RTU
- free configuration S-Config software
Specifications
- Power Supply: 19V ÷ 50V DC; 16V ÷ 35V AC or 85 ÷ 260V AC/DC
- Power Consumption: For 85 ÷ 260V AC/DC and 16V ÷ 35V AC power supply: max. 4,5 VA; 19V ÷ 50V DC power supply: max. 4,5 W
- Display: LED, red, 4 x 57 mm, with 8-step adjustment of brighness
- Resolution: 1 minute
